Level Selector

Showing 91–99 of 125 results

1-09100

Weight	0.004 lbs / 0.064 oz / 1.814 g
Diameter	0.610" (15.5mm)
Sensitivity	45 min/.1" (35min/2mm)
Fluid	Clear
Configuration	One Circle

Total: $8.07

1-11100

Drawing Available

Weight	0.006 lbs / 0.096 oz / 2.722 g
Diameter	0.748" (19.0mm)
Sensitivity	45 min/.1" (35min/2mm)
Fluid	Clear
Configuration	One Circle

Total: $8.04

4-1501

Drawing Available

Type of Mounting: Horizontal
Length: 49.5mm
Width: 39.7mm
Height: 13.0mm
Housing Material: Acrylic
Housing Finish: None
Vial Material: Plastic
Sensitivity (Nominal): 40 minutes per 2mm
Fluid Color: Yellow-green
Mounting Hole Size: 4.2mm
Center to Center: 25.8mm

Total: $7.16
4-1506

Drawing Available

Type of Mounting: Horizontal
Length: 66mm
Width: 44.8mm
Height: 13.0mm
Housing Material: Acrylic
Housing Finish: Orange
Vial Material: Plastic
Sensitivity (Nominal): 40 minutes per 2mm
Fluid Color: Yellow-green
Mounting Hole Size: 4.2mm
Center to Center: 25mm

Total: $4.50
4-2506
Type of Mounting: Horizontal
Length: 70.0mm
Width: 15.0mm
Height: 17.5mm
Housing Material: Acrylic
Housing Finish: None
Vial Material: Plastic
Sensitivity (Nominal): 35 minutes per 2mm
Fluid Color: Yellow-green
Mounting Hole Size: 4.2mm
Center to Center: 55.0mm

Total: $4.01
J-2850
Conic, or cupped, mounting spring is formed and heat treated, providing a compression-type adjustment when placed between the mounting surface and the bottom of the level housing. This type of design provides for a heavier, more rigid spring, and is used with the 2-24000 Circular Levels. Each spring has three (3), equally spaced, holes to accommodate mounting screws. Material: Beryllium Copper

Total: $3.85
4-3500

Drawing Available

Type of Mounting: Horizontal
Length: 98.0mm
Width: 16.0mm
Height: 16.0mm
Housing Material: Acrylic
Housing Finish: None
Vial Material: Plastic
Sensitivity: 35 minutes per 2mm
Fluid Color: Yellow-green
Mounting Hole Size: 4.2mm
Center to Center: 75.7mm

Total: $3.44
